Mounting the OpenCom 150 Rack InfoCom System
6.2

Technical Data

(only if different from the OpenCom 150)
Dimensions:
■
Width: 19-inch panel with flange for mounting in installation cabinet
■
Height: 3U
■
Depth: approx. 340 mm
Weight:
approx. 7.8 kg
Connection of 230 VAC power supply on rear side via inlet connector for non-
heating apparatus
Connection of all ports via RJ 45 jacks on front panel
Note: The ISDN S
switched in one direction (internal or external). Use of the ex-
ternal port with a crossover (Rx-Tx) patch cable in parallel to
the S internal port (for two S
0
may severely limit the range of the S
ports on the front panel may only be
0
terminals on the same bus)
0
Technical Data
bus.
0
