Voice over IP (VoIP)
an IP address from the OpenCom 100 IP network which is not being used, such
as 192.168.99.253 under IP Address Configured. Click on Apply.
3. Install a memory card (MMC or MMCPlus). Call up the System: Components
page. Select the "Firmware Addons" option. Click on Browse and select a
"fwaddons_*.cnt" file from the installation CD. Click on Load to load the oper-
ation software for the VoIP system telephones to the memory card.
4. Go to the page Telephony: Devices: VoIP Telephone and click on New. Enter
the MAC Address printed on the underside of the IP system telephone. Select
the Type and enter an internal Number. Option: enter an IP address from the
OpenCom 100 IP network which is not being used. Click on Apply.
5. Connect the IP system telephone's LAN connection to the LAN and connect the
phone to the mains power using the power supply unit provided.
Once your IP system telephone has been successfully started, you can set it up and
use as you would any other U

9.1.2 External SIP Line

If your OpenCom 130 / 150 has access to the Internet, you can an easily and
quickly set up an SIP line.
1. Request at least one SIP account from an SIP provider.
2. Install a Media Gateway card (see MGW Interface Card starting on page 114).
3. Call up the Configurator and go to the page Telephony: Ports: Slots. Click on
the corresponding slot. Under Configured, select MGC VoIP. Optional: enter
an IP address from the OpenCom 100 IP network which is not being used, such
as 192.168.99.253 under IP Address Configured. Click on Apply.
104
-based system telephone.
pn
Note: Use a shielded CAT-5 Ethernet cable (STP cable,
Shielded Twisted Pair cable) to connect an IP telephone to a
Local Area Network (LAN).
Note: The OpenCom 131 cannot be operated with a Media
Gateway card. This is why SIP telephony is not supported.
Quick Start
