PBX Cascading

11. PBX Cascading
As requirements grow, the OpenCom 100 can be operated together with other
PBX installations. If you merely need a larger number of connections, it is easy to
link a second PBX (PBX Cascading). If you want to operate the OpenCom 100 at
several locations with different PBXs, this is possible by PBX Networking (see
page 153).
Please also refer to the short installation guide "OpenCom 100 cascading set"
which is available as PDF file.
11.1

Variants of PBX Cascading

You can combine two PBXs in order to increase the number of terminals that can
be connected. A master PBX and a slave PBX are connected to one another by
means of two cables. The two PBXs essentially function like a single PBX with a
higher number of ports. The master PBX controls the slave PBX. The following PBXs
from the product family can be used for cascading:
Master system
OpenCom 130
OpenCom 150 Rack
For the PBX Cascading you will need a licence. The licence agreement provides
you with the necessary steps to activate this function.
11.2

Functionality of PBX Cascading

PBX cascading requires two twisted-pair leads with RJ45 plugs between the PBXs:
■
Voice data: one lead with all eight pins wired 1 to 1. Connect this to the PCM
ports of the PBXs. The shielded CAT-5 lead may be up to three meters long.
148
Note: It is not possible to cascade an OpenCom 131 with an-
other communications system.
Variants of PBX Cascading
Slave system
OpenCom 130
OpenCom 150 Rack
