Configuration
For the initial configuration you can connect the PC to the OpenCom 100 via the
Ethernet port. The TCP/IP network protocol is used to set up a connection via one
of these ports. You can then open the Web console of the OpenCom 100 and call
up the Configurator from there.
7.1

Brief Guide to Initial Configuration

Setting up a first connection is quite simple with a standard Windows PC:
1. Connect the PC's network card with one of the OpenCom 100.'s LAN ports Use
a cross-wired Ethernet cable to do this. You can also use an uncrossed Ethernet
cable for a connection via a LAN port to the OpenCom 130's expansion
module.
2. Windows 2000/XP: log on as a user with "Administrator" rights.
3. You will find the IP settings in Windows 2000/XP under Start: Settings:
Network connections: Local Area Connection. Open the dialogue box Local
Area Connection Properties, and then the dialogue box Internet Protocol
TC/IP Properties (see figure: Setting the IP address in Windows XP on page 78).
4. Note down the existing settings so that you can restore them after completing
the initial configuration.
5. Change the IP Address to 192.168.99.253. Change the subnet mask to
255.255.255.0, confirm with OK and Close.
6. Start a Web browser and in the address field enter "http://192.168.99.254/".
The Web console's log-on page will be displayed. Enter the user name "Adminis-
trator" without a password for the initial configuration.
Note: To avoid problems with existing network installations,
the OpenCom 100's DHCP server is designed for static ad-
dress assignment in its factory settings. The OpenCom 100's
IP address is always 168.99.254 in its factory settings.
Note: To support your next configuration steps, you should
activate the Assistant mode on the entry page of the Con-
figurator. Please also pay attention to the online help.
