Configuring the PC Software
Configuring the TAPI Connection
1. In the Start menu, select Settings: Control Panel. Select the Printers and
other Hardware (with Vista: Hardware and Sound) category. Double-click on
the Phone and Modem Options icon.
2. Change to the Advanced tab.
3. From the list of installed driver software, select Aastra 800/OCX/OpenCom
Service Provider and click on Configure.
4. In the following dialogue you will find a list with the configured connections
for the user who is currently logged on. Click on New.
5. In the following dialogue you provide information for the new connection. In
the Connection name box you can enter a descriptive name for the con-
nection. In the CTI server box you must enter the DNS name or the IP address
of the OpenCom 100. Using the [...] button you can search for this in the LAN.
In the boxes Username and Password you enter the user data of one of the
users configured on the OpenCom 100. This user must be allocated a system
terminal. Confirm your entry with OK.
6. The new connection is now configured. Close the opened dialogues with OK
and Close.
Testing the TAPI Function
1. In the Start menu, select Programs: Accessories: Communication and then
start the programme called Phone Dialer.
Under Windows XP and Vista, the Phone Dialer is started indirect by using the
dialling function of the Address book (can be found in the start menu under
Programs: Accessories). A manual start of the programme file "Dialer.exe" in
the "C:\Program Files\Windows NT" (XP) or "C:\WIndows\System32" (Vista)
folder is possible also.
2. In the Tools menu, select the item Connect using... to select the system ter-
minal that is to use the CTI application. Under Windows XP you select the item
Note: Under Windows you should log on as the user for
whom you want to configure the TAPI connection.
Setting up TAPI
