EasyDrive CV3100 Series Instruction Manual page 106

CV3100 series and MINI series high performance general purpose inverter instruction manual
P5.08 Delayed time to analog input signal
Setting range
This parameter is used for filtering analog signal input by terminal AI1, AI2 and
potentiometer on the keypad basing on the setting delayed time, in order to remove
effect by interference signal. If the time set is too long, it will reduce responding speed
of given signal.
AO1 multi-functional analog output
P5.09
terminal function selection
DO3 multi-functional pulse output
P5.10
terminal function selection
Setting range
AO1 is multi-function analog output terminal; DO3 is multi-function pulse output
terminal. Their function setting as below：
0：Output frequency
Analog output width or pulse output frequency is positively proportional to inverter
output frequency.
AO1：（0-AO1 upper limit）~（0.00-upper limit frequency）
DO3：（0-DO3 upper limit）~（0.00-upper limit frequency）
1：Setting frequency
Analog output width or pulse output frequency is positively proportional to inverter
setting frequency.
AO1：（0- AO1 upper limit）~（0.00-setting frequency）
DO3：（0-DO3 upper limit）~（0.00-setting frequency）
2：Output current
0.1—5.0s
0 Output frequency
1 Setting frequency
2 Output frequency
3 Motor rev.
4 Output voltage
5 Bus voltage
6 PID ration
7 PID feedback
6-38
Factory setting
Factory setting
Factory setting
0.5s
0
2
