EasyDrive ED3100 Series Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
ED3100 series and MINI series high performance general pupose inverter instruction manual
Thanks for your purchase of ED3100 series and MINI series inverter
manufactured by us.ED3100 series and MINI series inverter is of sensor-less
vector control frequency inverter with high torque, high accuracy and wide
range of speed regulation, designed with the brand-new idea. Based on
improving stability, it is provided with many run and control functions such as
motor parameters auto-tune, simple PLC control, practical PID adjustment,
flexible input/output terminal control, parameter online amendment, pulse
frequency setting, power-off and stopping parameter storage, wobbling control ,
RS485 communication, constant pressure water supply control and so on. This
inverter provides equipment manufacturer and terminal user with integrated
solution of high integration level; helps to reduce the system purchase and
operation cost, and improves the reliability of system.
Before using ED3100 series inverter, please read this manual carefully, so
as to install and operate inverter correctly and enable it produce the best
performance.
It is to be noted that this manual is subject to change without notice, and
please refer to new edition.
Reader range
This manual is suitable for following persons:
Installer of inverter, engineering technician (electric engineer, electric operating
worker), designer
Please make sure that this manual is delivered to the end user.
Stipulation of this manual
Stipulation of symbol
Warning
Conditions that cause medium injury or light injury due to operation
not accord to requirements
Danger
Conditions that cause death or serious injury due to operation not
accord to requirements
Preface
- 1 -
