Installing the Speaker

WARNING
Turn the workstation off and unplug the power cord before
removing or installing the speaker. Reference "Safely Powering
Down the B2000 Workstation" on page 12.
CAUTION
To prevent damage to the B2000 workstation, observe all of the ESD
precautions described in "Electrostatic Discharge (ESD) Precautions" on
page 9.
NOTE
Carefully position the cables to avoid damage while installing the fan/speaker
bracket in the chassis.
To install the speaker perform the following steps:
1. Install the speaker by positioning it so that the speaker cable can be easily run out of
the hole in the back of the mounting bracket. See Figure 4-20. Note that the speaker
cable must be held in place on the backside of the mounting bracket by the speaker
cable clips as shown in Figure 2-71. Once you have the speaker in the correct position,
pull outward on the speaker mounting clips and put the speaker in place. Then release
the mounting clips so that they hold the speaker on the mounting bracket.
2. Replace the fan/speaker bracket in the chassis by inserting the bottom and in first
between the system board and the CD cage. Insert the edge into the slots provided an
then rotate it into place until the mounting clip snaps into place.
3. Position the fan power cable, speaker cable and LCD ribbon cable so that they run along
the system board side of the computer chassis. Dress the cables so that they are free
from damage by other system components.
4. Replace the air divider. See Figure 2-63.
5. Replace all PCI (I/O) cards in their proper location.
6. Replace the left side panel and the front bezel. Refer to "Front Bezel and Left Side
Panel" on page 15.
7. Turn to Chapter 3, "Wrapping Up," on page 85 to complete this procedure.
Chapter 2
Parts Replacement Procedures
Speaker
81
