Speaker

This section describes how to remove and replace the workstation speaker.
WARNING Turn the workstation off and unplug the power cord before
removing or installing the speaker. Reference "Safely Powering
Down the B2000 Workstation" on page 12.
CAUTION To prevent damage to the B2000 workstation, observe all of the ESD
precautions described in "Electrostatic Discharge (ESD) Precautions" on
page 9.

Removing the Speaker

1. Remove the workstation left side panel. the speaker resides in a fan/speaker bracket
near the top of the workstation.
2. Remove the PCI retainer clip and all PCI cards. Refer to "Removing I/O Cards" on page
26.
3. Remove the air divider. See Figure 2-63. on page 72.
4. Unplug the speaker and fan cable to the system board and lift up on the bracket
mounting clip.
5. Grasp the fan/speaker bracket and rotate approximately 15 degrees to the left. Move
the entire fan/speaker bracket to the left or the rear of the chassis and remove.
6. Insert a finger through the access hole and push the speaker from the bracket while
spreading the two mounting clips. The speaker will pop free of the mounting clips.
