Parts Replacement Procedures
Memory DIMMs
CAUTION To prevent damage to the B2000 workstation, observe all of the ESD
precautions as described in the "Electrostatic Discharge (ESD) Precautions"
on page 9.
1. Open the side panel of the workstation as explained in the section "Opening the Left
Side Panel" on page 16 in this chapter.
Figure 2-7 System Board View
Figure 2-8. DIMM Slot Close-Up on System Board
DIMM Connectors
22
Power
Supply
(4 slots)
DIMM connectors
B2000
System Label
Chapter 2
