Parts Replacement Procedures
System Board
5. Plug-in the following cables:
• Speaker cable
• LCD ribbon cable
• PCI fan cable
• CD audio cable
• CD data cable
• Floppy drive data cable
• System fan cable
Figure 2-61. System Board Cables
System
Board Cable
70
Speaker Cable
LCD Cable
PCI Fan Cable
CD Audio Cable
CD Data Cable
Floppy Data Cable
