System Board

System Board
This section describes how to remove and replace the system board.

Removing the System Board

WARNING Always unplug the workstation's power cord from the electrical
outlet or power source before opening the workstation.
CAUTION To prevent damage to the B2000 workstation, observe all of the ESD
precautions described in "Electrostatic Discharge (ESD) Precautions" on
page 9.
Perform the following steps to remove the System Board.
1. Remove the workstation left side panel. Position the workstation right-side flat on a
cushioned stable tabletop.
2. Remove the following components:
• Power Supply
• PCI Retainer Clip
• Air Divider
• I/O Cards (if installed)
• Memory Card(s)
• Hard Disk Drive(s) and
hard disk drive bracket(s)
• Voltage Regulator Modules
(Master and Slave VRMs)
66
"Removing the Power Supply" on page 57
"Removing the I/O Card Retainer" on page 27
"Removing the Air Divider" on page 72
"Removing I/O Cards" on page 26
"Removing Memory DIMMs" on page 21
"Removing a Hard Disk Drive" on page 49
"Removing VRMs" on page 63
Chapter 2
