PCI I/O Card(s)

This section describes how to remove and install I/O cards.
Your B2000 workstation's system board has four Peripheral Connect Interface (PCI) slots
for option boards. Slots 1 and 2 are full-size PCI slots. Slots 3 and 4 are half-size PCI slots.
Figure 2-10. PCI Card Slot Numbering and Capabilities
The information described in Figure 2-10. is located inside your workstation on the chassis
floor. See Figure 2-11. for the physical location of the B2000 workstation label.
Figure 2-11. Location of B2000 System Label
Chapter 2
Slot 1 64 bits, 33MHz, 5V
Slot 2 64 bits, 33MHz, 5V
Slot 3 32 bits, 33MHz, 5V
Slot 4 32 bits, 33MHz, 5V
Parts Replacement Procedures
PCI I/O Card(s)
B2000 System Label
