Product Overview; Product Specifications - INVT Goodrive800 Pro Series Hardware Manual

Goodrive800 Pro Series Inverter Unit Hardware Manual
For Goodrive800-51 series inverter units, the rated power of a single unit is 355kW–720kW, while that of
parallel units can be up to 4100kW. The inverter unit consists of fuse, bus capacitor, IGBT, output reactor,
and other components. It is compact in structure and easy to integrate and maintain.

2.1 Product specifications

Description
Power input
Power output
Environment
condition
Mechanical
data
Protection
functions
202202 (V1.0)

2 Product overview

Table 2-1 Product specifications
Input voltage 510~720V DC 3PH, ±10%, -15% < 1min
(V) 700~1035V DC 3PH, ±10%, -15% < 1min
Input current
See section 2.3 Product ratings.
(A)
Input
frequency 50Hz or 60Hz; Allowed range: 47–63Hz
(Hz)
Output
Input voltage * 1.35
voltage (V)
Output
See section 2.3 Product ratings.
current (A)
Output power
See section 2.3 Product ratings.
(kW)
Working
≥98.5% (at the rated current)
efficiency
Working -10°C – +50°C; Derating is required when the ambient
temperature temperature exceeds 40°C.
Relative
5%–95%, no condensation
humidity
Installation Below 1000m (Derating is required when the altitude exceeds
altitude 1000m. Derate by 1% for every increase of 100m.)
Anti-vibration
Compliant with 3M4 vibration level in GB/T4798.3
performance
For the module: IP00
IP rating
For the cabinet: IP20 (Optional: IP23 and IP42)
Safety
Compliant with EN 61800-5-1
performance
Cooling
Forced air cooling
method
Including functions of protection against short circuit,
Protection
overcurrent, overload, overvoltage, undervoltage,
functions
overtemperature, and phase loss
Specifications
Product overview
5
