230
11.1 LR8400-20, LR8401-20, LR8402-20 Memory HiLogger Specifications
Trigger Function
Trigger method
Trigger modes
Trigger timing
Trigger source
Analog input
Integrated pulse input 8 channels (P1-P8)
Digital input
External trigger
Timer trigger
Trigger criteria
Trigger types
analog* and pulse
Level Trigger
Window Trigger
Trigger types digital
Pattern Mask Trigger Trigger when signals match the pattern mask (1, 0, and X)
Trigger level resolution (Analog) 0.1% f.s. (f.s. = 10 divisions)
Pre-trigger
Trigger output
Trigger output termi-
nal
Digital comparison
Single or continuous
Start, stop, start&stop
30 channels (U1-1 to U2-15), or up to 60 channels (U1-1 to U4-15) with
additional input units
8 channels (L1-L8)
Trigger on external input signal rising or falling edge (selectable).
Rising : triggers upon transition from 0 to 1.0 V (LOW)
Falling : triggers upon transition from 2.5 to 5.0 V (HIGH)
Trigger input voltage : 0 to 10 VDC
range
External trigger filter : On/Off
Minimum response : H period 2.5 ms or greater, L period 2.5 ms or
pulse width
Trigger input termi- : M3 screw type terminal
nals
Set year, month, day, hour, minute, and second
• AND or OR of each trigger source
• Trigger criteria can be set for each channel.
• Free-running when all are Off
Triggering occurs when the signal rises (or falls) through a specified value.
Triggering occurs when the input signal level enters or exits the amplitude
window defined by upper/lower thresholds.
(where X is "ignore")
(Pulse) Integration 1c, revolution 1/n (where n = pulses/rev)
Time span setting (any span).
Settable with real-time saving.
Open-collector output (with 5 V output, Active Low)
Pulse Width: at least 10 ms
M3 screw type terminal
to 2.5 to 5.0 V (HIGH).
to 0 to 1.0 V (LOW), or when the external trigger
terminal is shorted to a GND terminal.
greater
