If no HTTP screen is displayed
1. Perform this procedure.
(1) Click [Tools]-[Internet Options]
(2) On the [Advanced]
[Use HTTP1.1 through proxy
(3) On the [Connections]
2. LAN communications may not be possible. See "When LAN Communication Fails"(p. 188).
What if the Remote Operating Screen does not appear?
Java may not be installed. To operate the HiLogger from a web browser, depending on the
PC's software environment, Java may need to be installed separately. In that case, down-
load and install JRE (Java Runtime Environment) from the Java web page.
Attempting to operate the HiLogger by multiple PCs at the same time may result in unin-
tended actions. Remote control operation should be performed from only one PC at a time.
If the security setting blocks the Remote Operating Screen from being displayed, add the
address of Model LR8400 (for example, http://192.168.1.2/DISP.HTM) to the exception
site list.
For more information, visit "Manage the Exception Site List" of the Java website at http://
docs.oracle.com/javase/7/docs/technotes/guides/jweb/security/exception_site_list.html.
http://docs.oracle.com/javase/7/docs/technotes/guides/jweb/security/
exception_site_list.html

Remote Operating

Click [REMOTE CONTROL]
Screen
Magnification
Click
• The displayed panel emulates the HiLogger's. Click the keys with the mouse to operate.
• Screen refresh time can be selected from Off, or 2, 10, or 60 seconds. Refreshing the
screen also refreshes the on/off state of the Start LED.
• The emulated screen can be enlarged or reduced.
10.4 Remote Measurement with the HTTP Server Function
to display IE settings.
tab, under HTTP 1.1 settings, enable
connections].
tab, click [LAN Settings], and disable
to view the current HiLogger screen in the web browser.
[Use HTTP1.1]
[Use a proxy
Refresh
Time
191
and disable
server].
