6.3 Loading Data on the HiLogger

6.3 Loading Data on the HiLogger
Previously stored binary waveform data, captured screen images and saved setting
configurations can be reloaded into the HiLogger (p. 123).

Loading a Setting Configuration

Setting configurations saved in the HiLogger's memory or on a removable storage can
be reloaded.
1
Select the
Screen.
2
Select [Load
Apply
The loading dialog appears.
Select whether to load
3
from HiLogger memory,
CF card, or USB flash
drive.
Apply
4
(If you selected [Memory])
Select [Load]
figuration you want to
load.
Apply
(If you selected
memory])
Select the configuration
file to load.
(CONFnnnn.SET)
Apply
HiLogger settings are reconfigured to
those in the loaded configuration file.
[Setting]
Set.].
for the con-
[CF Card], or [USB
When Loading from HiLogger Memory
The list of configurations stored in HiLogger mem-
ory is displayed.
When Loading from removable storage
Configuration files stored in the [HIOKI_LR8400]-
[CONFIG] folder on the removable storage are
displayed.
To Save a Setting Configuration: (p. 133)
See:
Setting configurations saved to removable
storage can be reloaded from the File screen
(as described on the next page).
