192
10.4 Remote Measurement with the HTTP Server Function
Start/Stop Measurement
Click
[START/STOP]
Click
Shows current
memory status
Click the buttons to operate.
Viewing Current Measurement Values
Click
[CURRENT DATA DISP]
Click
• While measuring, you can monitor numerical data acquired from each channel at
every recording interval. Screen refresh time can be selected from Off, or 5, 10, or 60
seconds.
• When measurement is stopped, instantaneous input data from each channel is dis-
played.
• You can select which input unit to display.
to display this screen.
Shows current mea-
surement status
to display current measurements.
Select the input unit to display,
and press the SET button.
Starts Measurement
Stops Measurement
