Resistance Measurement

<Connecting to the terminals of the Universal Unit>
Required items: phillips screwdriver (for M3 screws), flat-blade screwdriver (tip width 2.6
mm), measurement leads
Recommended wire diameter:Single strand diameter: φ0.4 mm - φ1.2 mm (AWG26-16)
Multi-strand: 0.2 mm
Standard insulation stripping length: 8 mm
1
With a Phillips screwdriver,
loosen the screws in the termi-
nal block cover, and lift the
cover.
2
Push in the button on the con-
nector with a flatblade screw-
driver.
5
4
3
3
With the button held in, insert
the cable into the cable con-
nection hole.
4
Release the button.
The cable is locked.
2
- 0.75 mm
2
button
2.4 Making Connections
2
(AWG24-20)
5
Connect to the measurement
object.
6
Replace the terminal block
cover, and tighten the screws.
Torque screws to no more than
0.6 N•m.
4-wire configuration
(2- and 3-wire configurations are not
supported)
