116

5.3 Confirming All Trigger and Alarm Criteria Settings

5.3 Confirming All Trigger and Alarm Criteria
Settings
You can view and change trigger and alarm criteria settings for all channels on the
[Trig & Alm] screen.
Select [Batch Proc]
1-1, 2-1, 3-1, 4-1, P1, and W1 to W16 to any other channel. Copied settings include level,
slope, and threshold values.
"3.9 Viewing and Editing with the All-Channel Settings List" (p. 76)
See:
Trig Func (p. 107)
Select On to enable triggering.
Alarm
Select On to enable alarms.
Press ENTER to display the dia-
log at the right for the cursor-se-
lected channel. Trigger and
alarm criteria for the selected
channel can be set.
to initialize settings and to copy trigger and alarm settings from channels
Input type
: Voltage
: Temperature (Thermocouple)
: Temperature (RTD)
: Humidity
: Resistance
: Integration
: Revolution
: Alarm
Channel-specific settings (start, stop and alarm trig-
gers) are displayed to the right of the list for the channel
selected (highlighted) by the cursor.
