Hioki Memory HiLogger LR8401-20 Instruction Manual page 106

94
4.2 Observing Waveforms
Selecting which
have their cursor values dis-
played
Select from the [AB Crsr]
options.
∗
• [All Ch]
Displays all channels. The cursor
selected for [Move]
played.(Selecting
plays the difference between A
and B cursor values.)
• [Ch Set]
Specify which channels to display
with A and B cursors. The cursor
values for the specified channels
are displayed.
∗
( : default setting)
To select which cursor to move
Select from the [Move]
∗
• A Cur
• B Cur
• AB Cur
∗
( : default setting)
About Cursor Types
Cursor Type Example
Trace Cursors
Vertical Cur-
sors
B
Horizontal
A
Cursors
channels
setting
is dis-
[AB Cur] dis-
setting options.
Press the outer left and right scrolling
keys to scroll in large steps.
Cursor Value
B
Displays the time and measurement values at the A/B cursors,
A
or the time and measurement differences between the A/B cur-
sors.
Displays the intersections (trace points) of cursors and wave-
B-A
forms.(the intersections of waveform traces of selected channels)
B-A
A B
Displays the time and frequency values at the A/B cursors, or
the time and frequency differences between the A/B cursors.
B-A
Displays the measurement values at the A and B cursors for
the selected channel(s), or the difference between A/B cursor
values. A/B cursors can be enabled for any channel.
B-A
Cursor Value for Specified
Channels
Changing Cursor Type
Select from the [Type]
∗
• Trace
• Vert (Vertical)
• Horz (Horizontal)
∗
( : default setting)
setting options.
