11.2 LR8500 Voltage/Temp Unit Specifications

11.2 LR8500 Voltage/Temp Unit Specifications
Product warranty
period
Period of guaranteed
accuracy
No. of Input Channels
Input terminals
Measurement objects
Measurement accuracy Per connected HiLogger specification
Conditions of guaran-
teed accuracy
Temperature and hu-
midity range for guar-
anteed accuracy
Operating environment Per connected HiLogger specification
Operating temperature
and humidity
Storage temperature
and humidity
Dimensions
Mass
Applicable Standards
3 year
1 year
15 channels (select voltage, thermocouple, or humidity for each channel)
M3 screw type terminal block (2 terminals per channel) Terminal block
cover mounting
• Voltage
• Thermocouple (K, J, E, T, N, R, S, B, W)
• Humidity (Only with Hioki Z2000 Humidity Sensor)
Per connected HiLogger specification
Per connected HiLogger specification
Per connected HiLogger specification
Temperature -10 to 50°C (14 to 122°F), Humidity 80% RH or less
(non-condensating)
Approx. 128W × 52.8H × 64.5D mm (5.04"W × 2.08"H × 2.54"D)
(sans protrusions)
Approx. 380 g (13.4 oz.)
Safety : Per connected HiLogger specification
EMC : Per connected HiLogger specification
