10.3 Using the Logger Utility

The supplied Logger Utility program provides PC control over HiLogger settings
and measurement data recording, and data observation.
Display on the PC screen waveform files that
were saved to removal storage on the HiLogger.
(Convert binary data to CSV format for importing to
spreadsheet programs on the PC.)
Configure HiLogger settings on the PC, and
transfer to the HiLogger.
For details such as Logger Utility operating instructions, read the instruction manual (PDF
file) provided on the CD.

Starting and Ending Logger Utility

Starting Logger Utility
From the Start Menu of Windows
ger Utility].
Click
Logger Utility starts with the settings in the same state as
when the software was last ended. When you want to initial-
ize the settings, click [Initialize All Settings]
menu.
Ending Logger Utility
Click [Exit Application]
click the [x] close button at the top right of the main screen.
®
, click
[All Programs]
from the File
from the File menu of the main screen. Alternatively, you can
10.3 Using the Logger Utility
Search event marks and mea-
surement data using various
criteria such as maxima and
fluctuation values.
Real-time measurement data
can be acquired by one PC via
LAN or USB from up to five
HiLoggers at once.
(Monitor waveforms, numerical val-
ues and alarm output status in real
time while measuring.)
-[HIOKI]-[Logger Utility] -[Log-
Click
