1.3 Names and Functions of Parts, Screen Configurations
CF Card Slot
Use to save data to a CF card.
Insert an optional CF card (p. 48).
USB Cable Port
Use for PC communications via USB. Connect the sup-
plied USB cable (p. 172).
AC Adapter Socket
Connect the supplied
9418-15 AC Adapter (p. 34).
POWER Switch
Turns the HiLogger on and off (p. 46).
Power Off
Power On
Right Side
(USB 2.0 mini-B receptacle)
Ethernet Jack (RJ-45)
Model Use for PC communications via LAN.
Connect an optional Model 9642 LAN Cable (p.
186).
USB Port
Use to save data to a USB flash drive.
Insert an USB flash drive (p. 48).
