8.2 Numerical Value Calculation Expressions

8.2 Numerical Value Calculation Expressions
AVE
Average
=
Maximum
value
Peak Value
(P-P)
Minimum
value
Maximum
Maximum
value
Value
Minimum
Minimum
Value
value
Maximum
Time to max-
value
imum value
Time to mini-
mum value
Minimum
value
Start of Measurement
When
[On]
Interval Cal-
Measurement
culation
(Auto Calc
only, P.156 )
When
[Ref
Time]
Measurement
n
1
∑
di
-- -
n
i 1
=
Peak value
Start of Measurement
Time to maximum value
Time to minimum value
Split Time
Start of End of
Measurement
Reference
Time
Split
Length
Start of
End of
Measurement
Obtains the average value of waveform data.
AVE: Average value
n: Data count
di: Data on channel number i
Obtains the value of the difference (peak-to-peak
value) between maximum and minimum values of
waveform data.
Obtains the maximum value of waveform
data.
Obtains the minimum value of waveform
data.
Acquires the time (s) elapsed from the start of re-
cording to maximum value. When there are two or
more maxima, this value is the first to occur.
Acquires the time (s) elapsed from the start of re-
cording to minimum value. When there are two or
more minima, this value is the first to occur.
When [Split Save] is enabled
Time]), calculation results are saved at the speci-
fied interval.
When [On]:
Set the [Split Length]. Calculation results for the
specified time span are automatically saved.
When [Ref Time]:
Set the [Ref Time] and
tion results starting from the reference time are au-
tomatically saved for the specified time span.
([On] or [Ref
[Split Length]. Calcula-
