3.2 Configuring Measurement Settings

3.2 Configuring Measurement Settings
Configure measurement settings on the
The available measurement methods are Normal Recording, Continuous Recording
and Repeat Recording.
The Setting screen cannot be displayed while measuring.
Start Measurement
([Repeat]: On)
Measure for the specified
recording length.
Measuring Method Setting Method
Normal Recording
Continuous
Recording
Repeat Recording

Time Setting by Key Operations

1
Select the
screen.
2
Move to a setting item.
Open the setting options
for the item to be set.
Select from the listed op-
tions.
Apply
Stop Measurement
Continuous Press
Recording surement continues until the stop-trigger criteria are
met.
Normal Measures for the specified recording time span.
Recording Measurement stops when the specified recording
time has elapsed.
Measurement can also be stopped by pressing
STOP
stop-trigger criteria are met.
Repeat When stopped by a stop trigger or elapsed recording
Recording time, measurement automatically restarts. Press
STOP
Set [Cont] to On.
Set [Cont] to Off, and set a
Set [Repeat] to On.
[Setting]
[Setting] screen.
STOP to stop measuring. Otherwise, mea-
before the end of the recording time, or the
to stop measuring.
[Record time] (measurement time span).
