4.3 Marking Waveforms and Searching Marks (Search Function)

Searching Event Marks

Any event mark can be found by searching.
1
Select the Waveform/Numer-
ical Value Screen.
2
When [Channel]
played, switch to [Event].
Apply
The event setting items are
displayed.
3
Select [MoveNo.].
Open the setting options for
the item to be set.
For the [MoveNo.]
select the number of the
event you want to find.
Apply
4
Select [Move].
Apply
The waveform with the specified
event number is displayed.
is dis-
You can search by incrementing and decre-
menting the event number.
setting,
PrevEvent
NextEvent
3
4
Search for the previous
event mark.
Search for the next event
mark.
