5.2 Alarm Output
Some alarm settings are available on the Waveform/Numerical screens.
On the [Gauge+Wave]
[ALARM CLR] (when alarm hold is enabled) can be set. (Alarm hold can only be set
when measurement is stopped.)
1
Select the [Gauge+Wave]
form/Numerical screen.
2
Select [PLS & ALM]
key.
Put the cursor here and press
directly select which input unit to display.
Hold
Selects whether to reset or hold (latch) alarm outputs while measuring. (can only
be set when measurement is stopped)
Buzzer (beeper)
Enables and disables the alarm beeper. (can be set while measuring or not)
ALARM CLR
When alarm hold is enabled, put the cursor here and press
alarm manually.
An alarm can be cleared only when the alarm criteria are no longer met.
Waveform/Numerical screen, the alarm beeper, alarm hold, and
Wave-
with the UNIT
ENTER to
ENTER to clear the
