11.1 LR8400-20, LR8401-20, LR8402-20 Memory HiLogger Specifications
Basic Specifications
Mass
Applicable Standards
Vibration endurance
External control
terminals
External Storage
CF card
Slot
Card capacities
Data formats
USB flash drive
CF card/USB flash drive
common functions
Communications Functions
LAN Interface
LAN
Connector
LAN Function
USB Interface
USB standard
Connector
USB Function
Approx. 1.8 kg (63.5 oz.) (LR8400-20, without 370 g battery pack)
Approx. 2.6 kg (91.7 oz.) (LR8400 with two LR8500s, without 370 g bat-
tery pack)
Safety EN61010
EMC EN61326 Class A
JIS D 1601:1995 5.3(1), Category 1: Vehicle, Condition: Category A equiv.
(45 m/s2 oscillating acceleration on X-axis for 4 h, and on Y- and Z-axes
for 2 h)
External trigger input, trigger output, four alarm channel outputs, ground,
+12 V output (@100 mA max.)
CompactFlash specification compliant, 1 slot
Hioki 9727 (256 MB), 9728 (512 MB), 9729 (1 GB), 9830 (2 GB)
FAT, FAT32
Connector: Series A receptacle
Files and folders can be copied between drives.
IEEE802.3 Ethernet 100BASE-TX DHCP, DNS
RJ-45
• Data acquisition and measurement criteria setting with the Logger Utility
• Setting and measurement by communications commands
• Manual file transfer by FTP server (from HiLogger memory or remov-
able storage).
• Auto sending files by FTP client (periodically transfer binary files from
removable storage during or after measurement)
• Remote control by HTTP server (remote control, start/stop measure-
ment, display current values, data acquisition to memory, FTP file
transfers, comment entry)
• E-Mailing (send mail upon start/stop triggering, alarm events, power out-
age recovery, and when internal memory or removable storage is full)
USB2.0 compliant High Speed
Series-mini B receptacle
• Data acquisition and measurement criteria setting with the Logger Utility
• Setting and measurement by communications commands
• USB Drive Mode (to transfer data from CF card to a PC)
