Performing An Analysis - Micromeritics DVVA II 4000 Operator's Manual

DVVA II 4000

Performing an Analysis

A blank analysis is always performed prior to the analysis, unless you select the Use Prior
Blank option. Do not place the prepared sample into the sample chamber until prompted to do
so.
Use of certain USB devices or the addition or removal of a USB device during an
analysis may cause a delay in data acquisition, resulting in a loss of data or the
cancellation of an analysis. Avoid the use of attached USB devices such as flash
drives, digital audio players, or cellular phones during an analysis. Additionally avoid
adding or removing USB devices during an analysis.
1. Wipe the upper and lower piston tips with a paper towel or Kimwipe
2. Insert the sample tray.
3. Close the safety shield, then press the
safety shield is not completely closed.
4. Select Unit > Sample Analysis; the Analysis dialog is displayed with the Open Sample
Information File dialog positioned on top.
5. Choose a file for your analysis and click
of the selected file is displayed.
You can also accept the next sequenced number and create a new file if desired. Use
the Replace All push button to replace file parameters, or the parameter files drop-
down lists.
400-42803-01 (Rev B) - July 2017
button. The analyzer will not operate if the
Reset
; the Analysis dialog containing the parameters
OK
Performing an Analysis
®
.
3-15
