Micromeritics DVVA II 4000 Operator's Manual page 88

Open
Material Properties
Add Log Entry
Replace All
Each of the individual tabbed dialogs contain a Replace push button if you wish only
to replace specific parameters and not the entire contents.
Save
Close
Basic
5-6
Enables you to choose the type of sample material you are
analyzing.The Material type is used to determine which carbon
property models are used for this particular carbon. For
example, a different equation is used to predict COAN for
Tread/Hard carbons than for Carcass/Soft carbons. If you select
Other, the COAN is not calculated.
Choose Other only when your material is something other than
Tread/Hard or Carcass/Soft.
Displays the Add Log Entry dialog
This dialog enables you to enter analysis and/or sample criteria
(not recorded automatically by the analysis program) to display
in the Sample Log report. You can make multiple entries by
selecting this push button as many times as you wish.
Allows you to replace the values of the current sample file with
those from an existing one. A dialog is displayed so that you
may select the file. The values are copied into the file; you may
edit them as needed. This replaces all parameters of the entire
sample information file.
Saves the information you have specified for this sample file.
Closes the dialog. If a file containing unsaved changes is
open, you are prompted to save before the dialog closes.
Displays the sample information file in the basic format.
