Calibration; Set Lower Piston Home - Micromeritics DVVA II 4000 Operator's Manual

DVVA II 4000

Calibration

The DVVA II 4000 is calibrated before it leaves the factory; calibration values and dates are dis-
played on the Unit Configuration dialog (accessed from the Unit menu).
All but one calibration listed on this drop-down menu can be enabled and performed only with
the assistance of a trained Micromeritics service representative using the Service Test Mode
(refer to
Service Test
Each dialog has the following push buttons:
Start
Cancel

Set Lower Piston Home

Zeroes and sets the position of the lower piston, the Set Lower Piston Home dialog is displayed.
If the Master switch on the rear panel is turned off, the position of the lower piston is reset (indi-
cated on the instrument schematic). Use this command to establish the home position before
operating the analyzer.
400-42803-01 (Rev B) - July 2017
Mode, page 8-19).
Starts the calibration procedure.
Cancels the procedure; all components return to a ready
state.
Calibration
6-17
