Micromeritics DVVA II 4000 Operator's Manual page 90

Open
Report Options
Mass
Skeletal Density
Bulk Density
Material Properties
Scan Rate
Ending Pressure
Recording Interval
Use Prior Blank
Measure Residual Volume
Time Between Cycles
Selected Reports
Save
Close
Advanced
5-8
Contains predefined Report Options files, some of which were
included with the analysis program. If this is a new file, this
field contains the one you specified as the default.
Click to view or edit file values.
Advanced
Enables you to enter the mass of the sample; 1.0000 gram, ±
0.05 (determined to nearest 0.0001 gram) is the recommended
amount of sample to use.
Enables you to enter the skeletal density (also known as the
true density) of your sample.
Enables you to enter the bulk density (sometimes referred to as
pour density) of your sample.
Enables you to choose the type of sample material you are
analyzing.The Material type is used to determine which carbon
property models are used for this particular carbon. For
example, a different equation is used to predict COAN for
Tread/Hard carbons than for Carcass/Soft carbons. If you select
Other, the COAN is not calculated.
Choose Other only when your material is something other
than Tread/Hard or Carcass/Soft.
These fields display the values and options for the selected
Analysis Conditions file; they may be edited if needed. Editing
the fields in the dialog does not change the values in the
Analysis Conditions file. Refer to
for a description of these fields.
5-10
Contains a list of available reports. The ones selected for the
current Report options file are indicated with a check mark;
you may select additional reports to generate if desired.
Saves the information you have specified for this sample file.
Closes the dialog. If a file containing unsaved changes is open,
you are prompted to save before the dialog closes.
Displays the sample information file in the advanced format,
allowing you to view or edit parameters.
DVVA II 4000
Conditions, page
Analysis
400-42803-01 (Rev B) - July 2017
