DVVA II 4000
Show graphic
Standard Pressure
Normalize Void Volume
Overlays
400-42803-01 (Rev B) - July 2017
Select this option to have a graphic display above the report
title. The graphic can be a bitmap (bmp) or an enhanced
metafile (emf). For example, you may wish to display your
company logo.
Click to choose the graphic, then enter the height and
Browse
width in the appropriate fields. This image can be edited, or
removed, from the report window.
Choose the type of pressure to be interpolated for the user
defined tabular reports, the Summary Report, the Pressure Table
Report, and the void volume normalization.
Applied: the force of the upper piston only
Geometric Mean: calculates a geometric mean of the applied
(upper piston) and transmitted (lower piston) forces.
Select this option to have the void volume normalized.
Displays the Graph Overlay Samples dialog.
Click to choose the file(s) you wish to use in the
Browse
overlay. You may select up to eight files. Use
field of its entry.
After choosing the file(s), select the Overlay samples option
for each report type you plan to overlay. Refer to
Overlay, page
Samples
Clear
for step-by-step instructions.
3-27
Open
to clear a
Multiple-
5-13
