Tim2 Option Register (Tim2_Or) - ST STM32L0x3 Reference Manual

RM0367
21.4.19

TIM2 option register (TIM2_OR)

Address offset: 0x50
Reset value: 0x0000
15 14 13
Res. Res. Res. Res.
Bits 15:5 Reserved, must be kept at reset value.
Bits 4:3 TI4_RMP: Internal trigger (TI4 connected to TIM2_CH4) remap
This bit is set and cleared by software.
01: TIM2 TI4 input connected to COMP2_OUT
10: TIM2 TI4 input connected to COMP1_OUT
others: TIM2 TI4 input connected to ORed GPIOs. Refer to the Alternate function mapping
table in the device datasheets.
Bits 2:0 ETR_RMP: Timer2 ETR remap
This bit is set and cleared by software.
111: TIM2 ETR input is connected to COMP1_OUT
110: TIM2 ETR input is connected to COMP2_OUT
101: TIM2 ETR input is connected to LSE
100: TIM2 ETR input is connected to HSI48 (see note below)
011: TIM2 ETR input is connected to HSI16 when HSI16OUTEN bit is set in
register (RCC_CR)
others: TIM2 ETR input is connected to ORed GPIOs. Refer to the Alternate function
mapping table in the device datasheets
Note: When TIM2 ETR is fed with HSI48, this ETR must be prescaled internally to the TIMER2
12 11 10 9
Res. Res. Res.
(except for category 3 devices)
because the maximum system frequency is 32 MHz.
General-purpose timers (TIM2/TIM3)
8 7 6
Res. Res. Res. Res.
RM0367 Rev 7
5 4 3 2
TI4_RMP
rw rw rw
1 0
ETR_RMP
rw rw
