General-purpose timers (TIM2/TIM3)
21.4.20

TIM3 option register (TIM3_OR)

Address offset: 0x50
Reset value: 0x0000
15 14 13
Res. Res. Res. Res.
Bits 15:5 Reserved, must be kept at reset value.
Bit 4 TI_RMP: Timer3 remapping on PC9
This bit is set and cleared by software.
1: TIM3_CH4 selected
0: USB_NOE selected
Bit 3 TI_RMP: Timer3 remap on PB5
This bit is set and cleared by software.
1: TIM3_CH2 selected
0: TIM22_CH2 selected
Bit 2 TI_RMP: Timer3 TI remap
This bit is set and cleared by software.
1: TIM3_TI1 input is connected to PE3, PA6, PC6 or PB4
0: TIM3 _TI1 input is connected to USB_SOF
Bits 1:0 ETR_RMP: Timer3 ETR remap
These bits are set and cleared by software.
10: TIM3_ETR input is connected to HSI48 divided by 6 provided HSI48DIV6EN bit is set
(see
others configurations: TIM3_ETR input is connected to PE2 or PD2
544/1043
12 11 10 9
Res. Res. Res.
Section 7.3.3: Clock recovery RC register
8 7 6
Res. Res. Res. Res.
(RCC_CRRCR))
RM0367 Rev 7
5 4 3 2
TI_RMP
rw rw rw
RM0367
1 0
ETR_RMP
rw rw
