Output port and pin function definitions as follows:
Pin Port Definition
1 OUT0
3 OUT2
5 P24V
7 OUT5
9 OUT7
11 OUT8
13 EMSST_B
15 OUT11
17 OUT13
19 OUT14
21 OUT16
23 P24V
25 EMSST_A
Table 5-2Digital Output port definition
Function DES
Common
output port
Common
output port
internal 24V
power supply
Common
output port
Common
output port
Common
output port
Relay B
interface
Common
output port
Common
output port
Common
output port
Common
output port
internal 24V
power supply
B Relay
interface
PIN Port Definition
2 OUT1
4 OUT3
6 OUT4
8 OUT6
10 P24V
12 SVST_B
14 OUT10
16 OUT12
18 P24V
20 OUT15
22 OUT17
24 SVST_A
Function DES
Common
output port
Common
output port
Common
output port
Common
output port
internal 24V
power supply
A Relay
interface
Common
output port
Common
output port
internal 24V
power supply
Common
output port
Common
output port
A Relay
interface
