Danfoss Vacon OPTEA Operating Manual page 48

VACON® NXP Advanced Safety Options
Operating Guide
Table 22: Digital I/O Group (G7.4.2.2)
Index Parameter Min
V7.4.2.2.1 –
DI1
DI2
DI3
DI4
V7.4.2.2.2 –
DO1
DO2
Table 23: Encoder Group (G7.4.2.3)
Index Parameter
V7.4.2.3.1 Encoder
Type
V7.4.2.3.2 Estimated
Speed
V7.4.2.3.3 Proximity
Sensor
V7.4.2.3.4 Encoder
Speed
V7.4.2.3.5 Encoder
Freq
48 | Danfoss A/S © 2021.06
Max Unit De-
fault
– – –
– – –
Min Max Unit De-
fault
– – – –
– – – –
– – – –
– – rpm –
– – Hz –
ID Description
–
Shows the logical value of the option board digital input. Updated
only for inputs that have safety functions assigned.
0 = The input is inactive
1 = The input is active
- = The input is not used
–
Shows the logical value of the option board digital output.
0 = The output is inactive
1 = The output is active
- = The output is not used
ID Description
–
Shows the encoder type specified in the parameter file. Values:
• None
• Increm. TTL
• Increm. HTL
• SinCos
–
Shows whether estimated speed is used in the parameter file. Val-
ues:
• Not in us
• In use
–
Shows the number of used proximity sensors in use. Values:
• None
• 1
• 2
–
Shows the average speed measured by the option board (encoder
and proximity sensors)
–
Shows the speed of the motor based on the encoder data.
Overview of the System
AQ319736045637en-000101 / DPD01798
