VACON® NXP Advanced Safety Options
Operating Guide

8.8 SLS Parameters

Table 76: SLS Parameters
Parameter Selection
Acknowledg-
Manual
ment Mode
Automatic
(SLS)
SLS Ramp
None
Monitoring
Ramp 1
Ramp 2
SLS t1 0...3 000 000
SLS td1 20...65535
SLS td2 0...65535
SLS td3 0...255
SLS 1 Limit 0...65535
SLS 2 Limit 0...65535
SLS 3 Limit 0...65535

8.9 SMS Parameters

Table 77: SMS Parameters
Parameter Selection
Acknowledgment
Manual
Mode (SMS)
Automatic
SMS Limit Plus 0...65535
SMS Limit Minus -65535...0
132 | Danfoss A/S © 2021.06
Unit Description
– Use this parameter to select if manual (external) acknowledgment is necessary to deacti-
vate the safety function after the request ends. If the selection is automatic, the function is
deactivated after the request ends.
– Use this parameter to select the ramp that is monitored.
ms
Use this parameter to set the time after which the SLS function must be reached.
This parameter is used in these conditions:
• When the SLS function is activated.
• When the SLS limit is changed to lower limit. For example from 500 rpm (SLS 2) to 300
rpm (SLS 1).
ms Use this parameter to set the time after the activation of the function during which the
ramp monitoring must start (when ramp monitoring is used).
ms Use this parameter to set the time during which the speed must stay below the selected
SLS limit speed before the function becomes reached.
ms Use this parameter to set the transition time that is permitted for the two SLS inputs to
reach the selected value before the new value of the request is evaluated. The first change
starts the time.
rpm Use this parameter to set the monitored speed limit for SLS 1 Limit. Setting the value to 0
does not disable the monitoring.
rpm Use this parameter to set the monitored speed limit for SLS 2 Limit. Setting the value to 0
does not disable the monitoring.
rpm Use this parameter to set the monitored speed limit for SLS 3 Limit. Setting the value to 0
does not disable the monitoring.
Unit Description
– Use this parameter to select if manual (external) acknowledgment is necessary to deac-
tivate the safety function after the request ends. If the selection is automatic, the func-
tion is deactivated after the request ends.
rpm Use this parameter to set the monitored maximum speed limit to positive direction
when the SMS function is active.
rpm Use this parameter to set the monitored maximum speed limit to negative direction
when the SMS function is active.
Parameter List
