Table 103: Input/Output Parameters
Input/output parameters
Digital Input 1
Digital Output 2
Table 104: General Parameters
General parameters
Drive Reset
Drive Acknowledgment
Table 105: SS1 Parameters
SS1 parameters
Acknowledgment Mode (SS1)
SS1 Monitoring
SS1 Ramp Monitoring
SS1 t1
SS1 td1
SS1 td2
1) and 2) indicate alternative options. Use values marked with the same number.
When you use the safety-aware Multipurpose drive application, the SS1 function is realized by the drive application when the SS1
function is requested from the Advanced safety option board. The ramp definitions for controlled ramp are taken from the ramp 2
of the drive.
Table 106: Configuration in Safety-aware Multipurpose Drive Application
Parameter
P2.12.1 S Stop Response
P2.4.2 Ramp 2 Shape
P2.4.4 Deceleration Time 2
Danfoss A/S © 2021.06
Configuration Examples
Value
SS1
SBC
Value
Enabled
Enabled 2)
Disabled 1)
Value
Automatic 1)
Manual 2)
Time
–
4.75 s
–
–
Value
Ramp 2
0
4 s
