VACON® NXP Advanced Safety Options
Operating Guide
Table 114: Configuration in the OPTBM: Used Safety Functions: SLS, SQS
Input/output parameters
Digital Output 1
Operator for Output 1
Group 3 for safe digital output 1
Digital Output 2
Operator for Output 2
Group 8 for safe digital output 2
With the above configuration for output 2, the output will indicate the execution of SQS. SQS can then be triggered either by exter-
nal request or violation of SLS. Both are indicated in the same way in the output allowing the external system to react to the safety
function.
Danfoss A/S © 2021.06
Configuration Examples
Value
Group 3
OR
SLS 1 Active
SLS 2 Active
SLS 3 Active
Group 7
OR
SQS Active
