VACON® NXP Advanced Safety Options
Operating Guide
Table 24: PROFIsafe Group (G7.4.2.4)
Index Parameter
V7.4.2.4.1 Safety Telegram
V7.4.2.4.2 F-Par SRC Addr
V7.4.2.4.3 F-Par DEST Addr
V7.4.2.4.4 F-Par WD Time
Table 25: File Info Group (G7.4.2.5)
Index Parameter
V7.4.2.5.1 File Name
V7.4.2.5.2 File Creator
V7.4.2.5.3 Company Name
V7.4.2.5.4 CRC
V7.4.2.5.5 CRC integer
Table 26: Diagnostics Group (G7.4.2.6)
Index Parameter
V7.4.2.6.1 Last Error Code
V7.4.2.6.2 SW Version
V7.4.2.6.3 HW Version
V7.4.2.6.4 FPGA Version

3.8.4 Fault Types

The Advanced safety option board has different fault types: critical fault, resettable fault, violation, and warning. The fault types of
the Advanced safety option board are not the same as the fault types of the AC drive. For more details on faults, see
tion of Faults on the Control
Danfoss A/S © 2021.06
Min Max Unit
– – –
– – –
– – –
– – –
Min Max Unit Default
– – – –
– – – –
– – – –
– – – –
– – – –
Min Max Unit Default
– – – –
– – – –
– – – –
– – – –
Board.
Default ID Description
– –
Shows the number of the used telegram. Values:
• ST 30
• ST 31
• ST 58000
– – Shows the value of F Source Address
– – Shows the value of F Destination Address
– – Shows the value of F WD Time
ID Description
– Shows the first 12 characters of parameter File name
– Shows the first 12 characters of parameter File creator
– Shows the first 12 characters of parameter Company (Parame-
ter file)
– Shows the CRC of the used parameter file in hex format
– Shows the CRC of the used parameter file in decimal integer
format
ID Description
– Shows the number of the last fault of the Advanced safety op-
tion board in hex format.
– Shows the software version of the Advanced safety option
board.
– Shows the hardware version of the Advanced safety option
board.
– Shows the FPGA version of the encoder interface board on the
Advanced safety option board.
Overview of the System
12.1 Presenta-
