VACON® NXP Advanced Safety Options
Operating Guide
Index
Parame-
Min
ter
P7.4.1.2.2
SafeF indi-
0
cation
Table 20: Encoder (G7.4.1.3)
Index
Parameter
P7.4.1.3.1
Reading Rate
(1)
1
The menu group is accessible only when the Advanced safety option board is installed in slot C.
Table 21: Safety Functions Group (G7.4.2.1)
Index
Pa-
Min
rame-
ter
V7.4.2.1.1
STO
–
V7.4.2.1.2
SS1
–
V7.4.2.1.3
SS2
–
V7.4.2.1.4
SQS
–
V7.4.2.1.5
SSR
–
V7.4.2.1.6
SLS 1
–
V7.4.2.1.7
SLS 2
–
V7.4.2.1.8
SLS 3
–
V7.4.2.1.11
SSM
–
V7.4.2.1.12
SMS
–
V7.4.2.1.14
SOS
–
V7.4.2.1.15
SBC
–
Danfoss A/S © 2021.06
Max
Unit
De-
ID
fault
2
–
0
–
Min
Max
Unit
Default
0
4
–
1
Max
Unit
De-
ID
Description
fault
–
–
–
–
Shows the status of the safety function.
Not in use = The function is not taken into use in the parameter file.
–
–
–
–
Inactive = The safety function is not requested.
–
–
–
–
Requested = The safety function is requested.
Active = The safety function is active. (The signal xxx Active is "1".)
–
–
–
–
Reached = The safety function is reached. (The signal xxx Reached is "1".)
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
Description
2 = "No Action", F20 not activated
Selects the control board firmware response to safety function status
changes.
0 = "Default", F46/F47/F48 activated as alarm (application may de-
crease the reporting level, e.g. warning -> no action)
1 = "Violat only", F48 activated as alarm, F46/F47 not activated
2 = "No Action", F46/F47/F48 not activated
ID
Description
–
Time used to calculate actual speed value. Note: Use value 1 in
closed loop mode.
0 = No
1 = 1 ms
2 = 5 ms
3 = 10 ms
4 = 50 ms
Overview of the System
