VACON® NXP Advanced Safety Options
Operating Guide
SLS parameters
SLS t1
SLS td1
SLS td2
SLS td3
SLS 1 Limit
SLS 2 Limit
SLS 3 Limit
Table 116: Input/Output Parameters
Input/output parameters
Digital Input 2
Digital Output 1
Operation for Output 1
Group 2 for safe digital output 1
Table 117: General Parameters
General parameters
Drive Reset
Drive Acknowledgment
Table 118: SQS Parameters
SQS parameters
Acknowledgment Mode (SQS)
SQS Type
SQS Monitoring
SQS Ramp Monitoring
SQS t1
SQS td1
SQS td2
Table 119: Speed Measurement Configuration
Speed measurement configuration
Encoder Type
Encoder power supply
Encoder reference signal
Danfoss A/S © 2021.06
Configuration Examples
Value
5.0 s
0 ms
20 ms
100 ms
250 rpm
0 rpm
0 rpm
Value
SLS 1
Group 2
OR
SLS 1 Reached
Value
Enabled
Disabled
Value
(No effect)
STO
–
–
–
–
–
Value
Sin/Cos
15 V
No reference signal
