VACON® NXP Advanced Safety Options
Operating Guide
Table 89: Safe Input Data
Technical item or function
Input Voltage (Active, logic 1)
Input Voltage (Inactive, logic 0)
Input Current (Active, logic 1)
Input Current (Inactive, logic 0)
Input Resistance
Galvanic Isolation
Short circuit protected
Active -> Inactive Debounce time
Inactive -> Active Debounce time
Allowed discrepancy time of physical inputs in one logical input
Conductor size/cross-section (AWG)
Number of outputs (general): 2 logical (2x2 physical).
Number of outputs (STO): 2 logical (2 physical).
Table 90: Safe Output Data
Technical item or function
Output Voltage (Active, logic 1)
Output Voltage (Inactive, logic 0)
Output Current (Active, logic 1)
Output Current (Inactive, logic 0)
Galvanic Isolation
Short-circuit protected
Diagnostic test pulsing
Diagnostic test pulse length
Diagnostic test sequence interval
Output channel discrepancy time
Conductor size/cross-section (AWG)
Output state in case of a fault
Combined maximum output current for the Digital Output (STO & normal) and 24V supply is 250 mA.
1
146 | Danfoss A/S © 2021.06
Minimum
17 V
–
–
–
No
Yes
Alternating between a simultaneous pulse and individual pulse sequences on each physi-
cal output. Delay of 10 ms between pulses.
–
–
–
2
0.2 mm (28)
All outputs are inactive.
Minimum
–
-3 V
3.0 mA
–
3 kΩ
No
Yes
4 ms
50 ms
–
2
0.2 mm (28)
Typical
24 V
0 V
–
–
200 µs
200 ms
–
–
AQ319736045637en-000101 / DPD01798
Technical Data
Typical Maximum
24 V 30 V
0 V 5 V
– 5.5 mA
– 2.0 mA
– –
– 500 ms
2
1 mm (18)
Maximum
27 V
5 V
100 mA (250 mA combined
(1)
0.1 mA
400 µs
–
–
2
1 mm (18)
)
