Outlet State/Control State Descriptions
The following table shows the differences between outlet state and control state
•
The outlet state is the current operating state of the outlet.
•
The control state is the last user-issued control action on the outlet.
Outlet State
Control State
On
On
Off
Off
Off
Pend On
Off
Reboot
On
Idle On
On
Idle Off
On
Wake On
Off
Wake Off
On/Wait
Off
Off/Wait
On
On/Error
(varies)
Off/Error
(varies)
Off/Fuse
On
On/Fuse
On
No Comm
(varies)
Description
Outlet is on.
Outlet is off.
Outlet is off and about to turn on in response to a sequence
timer.
Outlet is off and a Reboot action has been initiated.
A restart has occurred – last control state has been
maintained.
A restart has occurred – last control state has been
maintained.
A power-loss has occurred – wakeup state has been applied.
A power-loss has occurred – wakeup state has been applied.
Outlet state in transition – re-query of outlet status required.
Outlet state in transition – re-query of outlet status required.
Error state – outlet should be off but current is sensed at the
outlet.
Error state – outlet should be on but no current is sensed at
the outlet.
Outlet should be on but a blown fuse has been detected.
Outlet should be on but a blown fuse has been detected
downstream
Communication to the outlet has been lost – control state will
be applied when communication is re-established.
PRO1 Sentry Switched DC PDU
67 of 211
