- Page 1 High Power PoE Injector (P/N DA2401) Owner’s Manual 1308147 REV. A 301 Fulling Mill Road, Suite G ©Copyright 2012 by Legrand, Middletown, PA 17057 Inc All Rights Reserved. Page (800)-321-2343 www.legrand.us...
- Page 2 All trademarks and brand names are the property of their respective proprietors. Specifications are subject to change without prior notification. 301 Fulling Mill Road, Suite G ©Copyright 2012 by Legrand, Middletown, PA 17057 Inc All Rights Reserved. Page (800)-321-2343 www.legrand.us...
- Page 3 TABLE OF CONTENTS 1.0 Introduction ........................ 1 1.1 Detailed Physical Description ................2 1.2 Installation ......................3 301 Fulling Mill Road, Suite G ©Copyright 2012 by Legrand, Middletown, PA 17057 Inc All Rights Reserved. Page (800)-321-2343 www.legrand.us...
- Page 4 1.0 Introduction The Legrand DA2401 4 Port High Power PoE Injector (see Figure 1) provides up to 30 Watts of power for any remote IEEE 802.3at high powered device, such as a third party multi-channel Wireless Access Point, PTZ (Pan, Tilt & Zoom) camera, or Speed Dome IP camera over Cat 5e/6 wiring. The DA2401 has four “Data”...
- Page 5 Figure 3 shows the DA2401 connection area including: Four Data Input RJ45 jacks 52-56VDC Power Input jack Four Data and Power Output RJ45 jacks Power LED – indicates DA2401 has input 52-56VDC power Four Port LEDs – indicates that port is providing 52-56VDC power Data & Data...
- Page 6 AC source. NOTE: If the DA2401 is going to be wall mounted, use the keyhole slots on the rear of the unit by hanging it on the screws that are first installed in the wall or on a piece of plywood.
