Sensor Graph Color-Coding
The sensor graph colors change dynamically to communicate operating conditions:
For Line (Load) Status
Green = Normal
Yellow = low warning/high warning (threshold configured by user)
Red = low alarm/high alarm (threshold configured by user)
Configure line current thresholds and threshold hysteresis at Configuration > System > Lines.
For Temperature Status
Violet = coldest; low alarm (threshold configured by user)
Blue = cold; low warning (threshold configured by user)
Green = acceptable temperature range
Yellow – warm; high warning (threshold configured by user)
Red = hot; high alarm (threshold configured by user)
Configure low/high temperature thresholds and threshold hysteresis at Configuration > System > Sensors.
For Humidity Status
Violet = wettest; high alarm (threshold configured by user)
Blue = wet; high warning (threshold configured by user)
Green = acceptable percentage of relative humidity
Yellow = dry; low warning (threshold configured by user)
Red = driest; low alarm (threshold configured by user)
Configure low/high temperature thresholds and hysteresis at Configuration > System > Sensors.

System Information

This section of the Summary page provides general information:
•
Firmware: Current firmware version
•
Uptime: Cumulative time the PDU has been up and running since the last unit restarted. Shows
continuous, real-time system updates with an approximate 5-second automatic refresh. A manual refresh
is not required.
•
Ethernet NIC S/N: The serial number of the PDU derived from the Ethernet NIC.
