Humidity Status
The Humidity graph displays a blinking warning or critical error whenever humidity exceeds low or high threshold.
The PDU continues to display the status until the condition changes or the issue has been resolved.
Humidity graph colors:
•
Violet = wettest; high alarm (threshold configured by user)
•
Blue = wet; high warning (threshold configured by user)
•
Green = acceptable percentage of relative humidity
•
Yellow = dry; low warning (threshold configured by user)
•
Red = driest; low alarm (threshold configured by user)
The default range of low/high relative humidity threshold values is 0-100%RH. Humidity threshold values are user-
defined at Configuration > System > Sensors.
Temperature/Humidity Sensor Status
Status Description
Found The PDU found the sensor and connection is established.
Not Found On a fresh reboot, the PDU does not find a sensor.
Lost The connection to a previously found sensor is now lost.
No Comm Communication loss occurred due to a hardware issue (not loss of communication with
the probes).
1 The ENV part of the sensor supports two temperature/humidity (T/H) probes as part of the master unit,
two T/H probes as part of the link unit, and the optional EMCU-1-1C (which can support two T/H probes, four
contact-closure monitoring points, and one water sensor). The "No Comm" sensor status is not loss
of communication with the probes themselves.
