Oip Carrier Wizard - Epygi Quadro2x Administrator's Manual

Quadro Baseline
VoIP Carrier Wizard
The VoIP Carrier Wizard is used to define access codes for available VoIP Carrier accounts which will particularly allow you to reach users over IP-
PSTN providers or to call to the peers registered on the certain SIP servers by dialing simple digit combinations.
For each configured VoIP carrier, the wizard creates a specific IP-PSTN routing rule in the
Call Routing table. Additionally, a virtual extension automatically generated in
Carrier's SIP server. The settings of that extension will be used to make calls from Quadro's users towards the created VoIP Carrier will be placed.
VoIP Carrier Wizard – Page 1 provides a following option of
describing the VoIP carrier:
When predefined carrier is selected in the VoIP Carrier drop
down list, the SIP Server and Port will be already predefined
in the next page. Manual selection allows you to manually
set up the VoIP Carrier settings.
The Description field allows you to insert an optional
description of the VoIP Carrier.
Quadro2x, Quadro2xi; SW Version 4.0.x
Quadro2x Manual II: Administrator's Guide – Administrator's Graphical User Interface
Table 9
The sorted list of
patterns
1231
123?
1[1-3]3[0-8]
?2?1
{100-150, asd, \*\?}1
[1-3]???
12*31
123*
*2*1
{11-15}3*
*1*
[1-3]*
*
E xtensions Management
3 1 4 H
3 1 3 H
will be registered on the defined VoIP
Fig. II-129: VoIP Carrier Wizard page 1
78
